CG VSR239p5 - Page 79

Emotron VS Series Quick Start Guide
- 78 -
Ten’s digit: Speed display（U0.05）
0: According to the actual speed
1: Multiply frequency by speed
coefficient(L0.11)
Hundred’s digit: Decimal places
0: No decimal places
1: One decimal places
2: Two decimal places
3: Three decimal places
L0.02
Keys locked option
0: Not locked
0
×
1: Full locked
2: Keys locked other than RUN,
STOP/RST
3: Keys locked other than
STOP/RST
4: Keys locked other than >>
L0.03
LED displayed parameters
setting 1 on running status
0～99(correspond U0.00～U0.99)
0
△
L0.04
LED displayed parameters
setting 2 on running status
0～99(correspond U0.00～U0.99)
6
△
L0.05
LED displayed parameters
setting 3 on running status
0～99(correspond U0.00～U0.99)
3
△
L0.06
LED displayed parameters
setting 4 on running status
0～99(correspond U0.00～U0.99)
2
△
L0.07
LED displayed parameters
setting 1 on stop status
0～99(correspond U0.00～U0.99)
1
△
L0.08
LED displayed parameters
setting 2 on stop status
0～99(correspond U0.00～U0.99)
6
△
L0.09
LED displayed parameters
setting 3 on stop status
0～99(correspond U0.00～U0.99)
15
△
L0.10
LED displayed parameters
setting 4 on stop status
0～99(correspond U0.00～U0.99)
16
△
L0.11
Speed display coefficient
0.00~600.00
1.00
△
L0.12
Power display coefficient
0.0~300.0%
100.0%
△
L0.13
The enable difference
range of U0.00 and U0.01
0.00Hz~5.00Hz
0.10Hz
△
Group L1 User-defined Display Parameters
L1.00
User-defined Display
Parameter 0
00.00～49.99
00.03
△
L1.01
User-defined Display
Parameter 1
00.00～49.99
01.01
△
L1.02
User-defined Display
Parameter 2
00.00～49.99
01.02
△
L1.03
User-defined Display
Parameter 3
00.00～49.99
01.08
△
L1.04
User-defined Display
Parameter 4
00.00～49.99
01.09
△
L1.05
User-defined Display
Parameter 5
00.00～49.99
02.00
△
L1.06
User-defined Display
Parameter 6
00.00～49.99
02.01
△
L1.07
User-defined Display
Parameter 7
00.00～49.99
02.12
△
L1.08
User-defined Display
Parameter 8
00.00～49.99
03.00
△
L1.09
User-defined Display
Parameter 9
00.00～49.99
03.01
△
