TechnicalSpecications
Shock wave source of the F-SW handpiece
Generation method electromagnetic
Focusing method parabolic reector
Energy settings minimum typical maximum
Energy ux density (mJ/mm
2
) 0.10 0.35 0.55
Peak positive acoustic pressure [MPa] 14 36 62
Peak negative acoustic pressure [MPa] 9 13 15
Axial focus size (-6dB focal zone) [mm] 57 49 34
Lateral focus size (-6dB focal zone) [mm] 5
4 3
Focus volume [cm
3
] 0.87 0.37 0.14
Derived acoustic pulse energy (r=2.5mm)
[mJ]
1.7 5.5 8.5
F-SW handpiece without stand-off device
Pressure wave generation electromagnetic
Pressure wave expansion focused
Focus size 5 mm x 5 mm x 30 mm
Depth of focus 50 mm
Depth of focal zone min. 35 - 65 mm
Therapeutically effective
penetration depth, 5 MPa
0 - 125 mm
F-SW handpiece with stand-off device I (short)
Focus size
5 mm x 5 mm x 30 mm
Depth of focus
30 mm
Depth of focal zone
min. 15 - 45 mm
Therapeutically effective
penetration depth, 5 MPa
0 - 105 mm
F-SW handpiece with stand-off device II (long)
Focus size
5 mm x 5 mm x 30 mm
Depth of focus
15 mm
Depth of focal zone
min. 0 - 30 mm
Therapeutically effective
penetration depth, 5 MPa
0 - 90 mm
Subject to technical changes
