TechnicalSpecications
Shock wave source of C-ACTOR handpiece
Erzeugungsart electromagnetic
Focusing method parabolic reector
Energy settings minimum typical maximum
Energy ux density (mJ/mm
2
) 0.25 0.76 1.24
Peak positive acoustic pressure [MPa] 18 44 78
Peak negative acoustic pressure [MPa] 12 20 23
Axial focus size (-6dB focus zone) [mm] 24 22 18
Lateral focus size (-6dB focus zone) [mm] 3.9
2.8 2.1
Focus volume [cm
3
] 0.2 0.1 0.04
Derived acoustic pulse energy (r=2.5mm)
[mJ]
3.3 9.5 15
C-ACTOR handpiece with stand-off device I (short)
Focus size 3 mm x 3 mm x 20 mm
Depth of focus 15 mm
Depth of focal zone min. 5 – 25 mm
Therapeutically effective penetration
depth, 5 MPa
0 – 50 mm
C-ACTOR handpiece with stand-off device II (long)
Focus size 3 mm x 3 mm x 20 mm
Depth of focus 0 mm
Depth of focal zone min. 0 – 10 mm
Therapeutically effective penetration
depth, 5 MPa
0 – 35 mm
Software version
The number of the software version of the device can be seen on the touch panel.
Pressing INFO / VERSIONS shows the actual software und hardware versions.
Subject to technical changes
