Chemyx Fusion Series - Specifications

15
Chemyx, Inc.
Fusion Series User Manual
Specifications
Specification
Fusion 100
Fusion 200
Fusion 400
Available Movement
Modes
Infusion
Infusion / Withdrawal
Infusion
Syringe Sizes
(Min/Max)
0.5 μL / 60 mL
0.5 μL / 60 mL
0.5 μL / 10 mL
Flow Rate Range
(Smallest Syringe)
0.0001 - 1.5679 μL/min
0.0001 - 1.5679 μL/min
2 - 10.536 pL/min
Flow Rate Range
(Largest Syringe)
0.0002 mL/min - 128
mL/min
0.0002 mL/min - 128
mL/min
4.83 pL/min - 2.1
mL/min
Drive Mechanism
1.8° stepper motor with
1/32 microstepping
1.8° stepper motor with
1/32 microstepping
1.8° stepper motor with
1/32 microstepping
Step Resolution
0.098 μm / μstep
0.046 μm / μstep
0.016 μm / μstep
Nominal Linear Force
16 kg (35 lbs)
23 kg (50 lbs)
23 kg (50 lbs)
Accuracy
± < 0.04% error (99.96%)
± < 0.04% error (99.96%)
± < 0.04% error (99.96%)
Reproducibility
± < 0.05% deviation
(99.95%)
± < 0.05% deviation
(99.95%)
± < 0.05% deviation
(99.95%)
Operation Temp
4°C to 40°C
(40°F to 104°F)
4°C to 40°C
(40°F to 104°F)
4°C to 40°C
(40°F to 104°F)
Storage Temp
-10°C to 70°C
(14°F to 158°F)
-10°C to 70°C
(14°F to 158°F)
-10°C to 70°C
(14°F to 158°F)
Relative Humidity
20% - 80%
20% - 80%
20% - 80%
Data Ports
RS-232 (DB9 and USB-
B), TTL (USB-B)
RS-232 (DB9 and USB-
B), TTL (USB-B)
RS-232 (DB9 and USB-
B), TTL (USB-B)
Height
11 cm (4.4 in.)
12 cm (4.7 in.)
13 cm (5.1 in.)
Width (Length)
24 cm (9.5 in.)
24 cm (9.5 in.)
24 cm (9.5 in.)
Depth
17 cm (6.8 in.)
17 cm (6.8 in.)
17 cm (6.8 in.)
Weight
3 kg (7 lb)
3 kg (7 lb)
3 kg (7 lb)
Screen
4.25" diagonal
3.7" X 2.1"
4.25" diagonal
3.7" X 2.1"
4.25" diagonal
3.7" X 2.1"
