Step Loop
The Step Loop field determines how many additional times to sequentially perform the
particular step. This is the lowest-level loop that iterates whenever that particular step is
reached and completed.
Example
In a multi-step method of five steps (1, 2, 3, 4, 5) where Step 4 has a Step Loop of “2”. The
method will run the following steps sequentially: 1, 2, 3, 4, 4, 4, 5. When the step loop is set to
“2”, Step 4 is repeated twice more. If the entire method also has a Loop All setting of “1”, the
method would run the following steps sequentially: 1, 2, 3, 4, 4, 4, 5, 1, 2, 3, 4, 4, 4, 5.
The Step Loop field takes any integer from 0 to 99. A value of 0 indicates that the method will
run the step only once. Any value above zero represents additional times to run the step.
In the Pump Running screen, the number of remaining loops of the current step appears on the
right, next to the repeat icon.
