Fusion Series User Manual
Running the Pump
The pump’s actions are controlled by the Stop, Pause, and Start keys on the front. In order to
start a run, the screen should be showing either the Basic Mode (for basic runs) or Multi-Step
Mode (for multi-step runs) main screens. Pressing the Start key in either other these screens
will start a run with the currently set parameters.
Pressing the Start button once will start a new run with the
currently displayed parameters or resume a paused run. This
button is only functional when a run is currently paused or when
the display is showing the Basic Mode or Multi-Step Mode
screens that show the current parameters.
Pressing the Start button while a delay countdown is occurring
will immediately skip the remaining delay time and start the
run/step.
Pressing and holding the Start button will begin priming, where
the pump will continuously run at the Prime/Bolus Rate as long
as the button is being pressed. The Prime/Bolus Rate is set in
Basic Mode > Options. Priming is only available in Basic Mode.
The green LED light on the Start button will be on while the
pump is running.
While the pump is running, pressing the Pause button will pause
the current run. Pausing allows the pump to continue the same
run from the point when the pause occurred.
The yellow LED light on the Pause button will be on when the
current run has been paused.
During a run, pressing the Stop button will immediately stop the
run, and return the display to the Basic Mode or Multi-Step
Mode screen.
While outside of an active run, pressing the Stop button will exit
the current screen. This result is the same as activating the “X”
button in the top right corner of the screen by touch or
navigational keypad.
The red LED light on the Stop button will be on whenever the
pump is neither actively running nor paused. The light will also
be on for active runs that are currently in a delay before starting
a step.
The red LED light will blink if the pump has stalled.
