Chloride ACTIVE 700 - Rear Side (Upright Devices) GB; Models ACTIVE 700 and ACTIVE 1000 GB

CHLORIDE ACTIVE Indicator and operating elements
945040.066 V02OCT/01 GB - 13
G
B
Rear side (upright devices)
Models ACTIVE 700 and ACTIVE 1000
COM 3 interface
COM interface (optional)
EXT. OUTLETS CONTROL
interface
USB interface
Fan
Output sockets (AC OUTPUT)
Mains connection (AC INPUT)
Input fuse
The fuse must only be changed when the
device is switched off and the mains con-
nection cable disconnected.
COM 3 interface
COM interface (optional)
EXT. OUTLETS CONTROL
interface
USB interface
Connection for battery extension
Fan
Output sockets (AC OUTPUT)
Mains connection (AC INPUT)
Input fuse
The fuse must only be changed when the
device is switched off and the mains con-
nection cable disconnected.
Fig. 3: Rear side ACTIVE 700
Fig. 4: Rear side ACTIVE 1000
