Chloride ACTIVE 700 - Connections (ACTIVE 700-19 to ACTIVE 3000-19)

Technical data CHLORIDE ACTIVE
GB - 44 V02OCT/01 945040.066
UPS model
ACTIVE
700-19
ACTIVE
1000-19
ACTIVE
2000-19
ACTIVE
3000-19
Mains connection
Model IEC 320 IEC 320
Nominal current 10 A 16 A
Fuse protection of mains supply 6 A 10 A 12 A 16 A
Load connection
Number 4 4 4 1
Model IEC 320 IEC 320 IEC 320 IEC 320
Nominal current 10 A 10 A 10 A 16 A
COM 3 interface SUB-D, 9 pin, pins
USB interface USB, type B
COM interface (optional) SUB-D, 9 pin, socket
EXT. OUTLETS CONTROL interface SUB-D, 9 pin, socket
Battery extension none plug, 3 pin
Table 15: Connections (ACTIVE 700-19 to ACTIVE 3000-19)
UPS model
ACTIVE
700-19
ACTIVE
1000-19
ACTIVE
2000-19
ACTIVE
3000-19
Signalling
LED indicator on front side
Acoustical alarm
Message
Signalling contact +5V … +12V (SIC)
Operation
Signal input +5V … +12V (SIC)
Interface RS 232
Table 16: Other data (ACTIVE 700-19 to ACTIVE 3000-19)
