Operational behaviour CHLORIDE ACTIVE
GB - 28 V02OCT/01 945040.066
Initially, all elements of the "LOAD" LED strip illuminate. Beginning with the
1 - 35 % indicator, the remaining elements in this LED strip are extinguished
one after the other. Afterward, the elements which correspond to the load
state of the device illuminate.
After approx. 5 seconds, the "BYPASS" indicator extinguishes and the
"INVERTER" indicator illuminates. The connected loads are supplied from
the mains supply via the inverter.
Battery test
The device must be in online operation.
With the device connected to mains, press the button for at least 1 second.
• The input is confirmed by a single acoustical signal, and the connected
load is now supplied by the battery for 10 seconds.
• The elements of the "BATTERY" LED strip correspond to the charging
state of the battery and the "LOAD" LED strip corresponds to the load
factor. The "MAINS" and "INVERTER" indicators illuminate. An acous-
tical signal sounds during the test (as in battery operation of the UPS).
• If the test has been completed successfully, the "BATTERY" LED strip
ceases to flash after approx. 10 seconds and the UPS returns to online
operation. If a problem exists with the batteries, an alarm is triggered.
