Indicator and operating elements CHLORIDE ACTIVE
GB - 14 V02OCT/01 945040.066
Models ACTIVE 2000 and ACTIVE 3000
EXT. OUTLETS CONTROL
interface
COM interface (optional)
USB interface
COM 3 interface
Connection for battery extension
Fan
Output sockets (AC OUTPUT)
Input circuit breaker
Mains connection (AC INPUT)
EXT. OUTLETS CONTROL
interface
COM interface (optional)
USB interface
COM 3 interface
Connection for battery extension
Fan
Output sockets (AC OUTPUT)
Input circuit breaker
Mains connection (AC INPUT)
'
' '
Fig. 5: Rear side ACTIVE 2000
Fig. 6: Rear side ACTIVE 3000
