CHLORIDE ACTIVE Technical data
945040.066 V02OCT/01 GB - 41
G
B
UPS model
ACTIVE
700
ACTIVE
1000
ACTIVE
2000
ACTIVE
3000
Mains connection
Model IEC 320 IEC320
Nominal current 10 A 16 A
Fuse protection of mains supply 6 A 10 A 12 A 16 A
Load connection
Number 4 4 4 2
Model IEC 320 IEC 320 IEC 320 IEC 320
Nominal current 10 A 10 A 10 A 16 A
COM 3 interface SUB-D, 9 pin, pins
USB interface USB, type B
COM interface (optional) SUB-D, 9 pin, socket
EXT. OUTLETS CONTROL interface SUB-D, 9 pin, socket
Battery extension none plug, 3 pin
Table 10: Connections (ACTIVE 700 to ACTIVE 3000)
UPS model
ACTIVE
700
ACTIVE
1000
ACTIVE
2000
ACTIVE
3000
Signalling
LED indicator on front side
Acoustical alarm
Message
Message contacts, see SIC option
Interface RS 232/USB
Operation
Signal input, see SIC option
Interface RS 232/USB
Table 11: Other data (ACTIVE 700 to ACTIVE 3000)
