7.7 Setpoint Menu (For Standard Model only)

Parameter Description Default Value

Enable Timer

Enabled - Enables the Delay and On Timers. Applies at

next power-up or next control enable.

Disabled - Delay and On Timers are ignored.

(Setpoint ramping still functions.)

Disabled

Delayed Start Time

Time from power-up or control enable before control be-

gins from 00.01 to 99.59 (hours & minutes) or OFF (0.00).

If delay is OFF control starts immediately.

OFF

Ramp Rate

Rate the actual setpoint changes from current PV to tar-

get setpoint following power-up or control enable.

From 0.001 to 9999 (Units / hr) or OFF (10000).

Any changes in the setpoint value also follow this rate.

OFF

On Time

The time the target setpoint will be maintained once

reached, from 00.01 to 99.59 (hours & minutes) or Off

(00.00)

Set to >99.59 for Inﬁnite - control remains on indeﬁnitely.

Inﬁnite

Upper Limit Used to limit the Maximum setpoint value. Scale Range Maximum

Lower Limit Used to limit Minimum setpoint value. Scale Range Minimum

Offset

For use in multi-zone setpoint slave applications.

Offsets the setpoint from -1999 to 9999. Effective SP =

SP+Offset. NOTE: effective SP is not limited by setpoint

limits.

‘Offset in use’ pop-up appears when SP is changed.

7.8 Setpoint Menu (For Extrusion Model only)
