43
13.11 Limiter - Communications Menu
Parameter Description Default Value
Unit Address Modbus address from 1 to 255
1
Baud Rate
Coms data rate in kbps
1200, 2400, 4800, 9600, 19200 & 38400.
9600
Parity Parity checking: Odd, Even or None.
None
13.12 Limiter - Display Menu
Parameter Description Default Value
Setup Unlock Code
View & adjust Setup mode lock code (password).
From 1 to 9999 or Off for no lock code.
10
Advanced Unlock Code
View & adjust Advanced mode lock code (password).
From 1 to 9999 or Off for no lock code.
20
Screen Timeout Screensaver time. Display turns off after 5, 15 or 30 mins. 5
Selected language Display language – English, German or French. English
Reset to Defaults
Used to reset all parameters back to the factory defaults.
See 1020 Controller Factory Defaults.
13.13 Limiter - Information Menu
Parameter Description
PRL
DOM
The hardware/software revision level. Shows the product update status.
Date of manufacture in the form of month and year, mmyy.
FW Version
FW Type
The firmware version number & code type.
Serial Serial Number of unit.
Out1
Out2
Out3
Shows factory fitted hardware options –
Output 1 can be: SSR (SSR driver) or Relay
Output 2 can be: SSR (SSR driver) or Relay
Output 3 can be: None, SSR (SSR driver), Relay or Linear
Comm
DI
RS485 communications option - Fitted or None.
Digital Input is isolated or not - Iso or NonIs – see the Isolation Chart
13.14 Limiter - Exiting from Advanced Configuration Mode
If necessary, press & to clear any Pop-Up
Alerts.
Press & to exit up one menu level. Repeat if
required.
Some menus have sub-menus so it may be necessary
to press this key combination more than once. For ex-
ample, to go back to the Operator screen from inside
the Output 2 sub-menu you need to go up 3 levels and
then press
& to exit the Advanced Configura-
tion mode.
