13
5.1 Navigating the Setup Screens
To access the Setup Mode from User Mode, press
& together. Enter code for Setup Lock (default = 10)
using & , then press .
5 Setup Mode
Lock Code 10 Lock code to enter Setup Mode. Default is 10
Parameter Name Description Meaning & Visibility
Input Type
-200 to 1200ºC
-328 to 2192ºF
-128.8 to 537.7ºC
-199.9 to 999.9ºF
J Thermocouple
-240 to 1373ºC
-400 to 2503ºF
-128.8 to 537.7ºC
-199.9 to 999.9ºF
K Thermocouple
-199 to 800ºC
-328 to 1472ºF
-128.8 to 537.7ºC
-199.9 to 999.9ºF
PT100
100 to 1824ºC 211 to 3315ºF B Thermocouple
0 to 2320ºC 32 to 4208ºF C Thermocouple
0 to 762ºC
32 to 1403ºF
0.0 to 537.7ºC
32.0 to 999.9ºF
L Thermocouple
0 to 1399ºC 32 to 2551ºF N Thermocouple
0 to 1795ºC 32 to 3198ºF R Thermocouple
0 to 1762ºC 32 to 3204ºF S Thermocouple
-240 to 400ºC
-400 to 752ºF
-128.8 to 400.0ºC
-199.9 to 752.0ºF
T Thermocouple
0 – 20mA 0 – 20mA
4 – 20mA 4 – 20mA
0 – 50mV** 0 – 50mV**
10 – 50mV 10 – 50mV
0 – 5V 0 – 5V
1 – 5V 1 – 5V
0 – 10V 0 – 10V
2 – 10V 2 – 10V
** 0 – 50mV is only linear dc input available on Extrusion models.
Input Units ˚C ˚F Select °C or °F temperature units – Default is °C
Units parameter hidden when linear input is used and units are not shown on the display
Input Decimal
Place
0000 00.00 Number of decimal resolution. (2 or 3 decimal
places only available.
000.0 0.000
