6 Advanced Configuration Mode
Lock Code 20
Lock code to enter Advanced Configuration
Mode. Default is 20.
Menu Name Meaning & Visibility
User
Provides access to User parameters including Control Enabled and Manual Control
Enabled parameters.
Input Set up input sensor and range.
Calibration For entering calibration points.
Outputs Set functions for up to 3 outputs.
Control Control settings for PID, or ON/OFF control, and Auto-tune.
Setpoint Setpoint and timer settings.
Alarm All alarm settings including sensor break alarm.
Comms Modbus address, baud rate and parity - only shown if RS485 option is fitted.
Display Lock code set up and Basic Setpoint Control enable/disable.
Operator Visibility setting for parameters that can be made visible in the User Mode.
Info
Revision level, Firmware version, Serial number and Manufactured date.
The Advanced Configuration mode gives access to all
the parameters accessible from the front panel; how-
ever, the device hides parameters that are not relevant
to your exact model code specification & configuration.
It may be faster to access some
parameters from the Setup Mode.
Press
& to enter Advanced Configuration from
Operator screen.
Enter Advanced Lock-code using & , then
press .
