Chromalox 1020 User Manual

58
Parameter Name HMI Mode
Modbus
Address
(Dec)
Modbus
Address
(Hex)
Access
R/W Notes
Output 3 Usage Outputs
1130
46A R/W
If Relay/SSR fitted:
0 = Heat Output
1 = Cool Output
2 = Non-Linear Cooling – Only Extrusion
3 = Alarm 1
4 = Alarm 2
5 = Alarm 1 or Alarm 2
6 = Loop Alarm
If Linear out fitted:
0 = Heat Output
1 = Cool Output
7 = Retransmit Setpoint
8 = Retransmit Process value
Output 3 Indicator
Invert
Outputs
1131
46B R/W
0 = Sync with output, 1 = Opposite to output
(e.g. ON when output off)
Output 3 Alarm
Latching
Outputs
1133
46D R/W 0 = Off, 1 = On (will latch on when active)
Output 3 Alarm
Action
Outputs
1132
46C R/W 0 = Direct, 1 = Reverse (off if alarm active)
Output 2 Indicator
Invert
Outputs
1121
461 R/W
0 = Sync with output, 1 = Opposite to output
(e.g. ON when output off)
Output 2 Alarm
Latching
Outputs
1123
463 R/W 0 = Off, 1 = On (will latch on when active)
Output 2 Alarm
Action
Outputs
1122
462 R/W 0 = Direct, 1 = Reverse (off if alarm active)
Output 2 Usage Outputs
1120
460 R/W
0 = Heat Output
1 = Cool Output
2 = Non-Linear Cooling – Only Extrusion
3 = Alarm 1
4 = Alarm 2
5 = Alarm 1 or Alarm 2
6 = Loop Alarm
Output 1 Indicator
Invert
Outputs
1101
44D R/W
0 = Sync with output, 1 = Opposite to output
(e.g. ON when output off)
Output 1 Alarm
Latching
Outputs
1103
44F R/W 0 = Off, 1 = On (will latch on when active)
Output 1 Alarm
Action
Outputs
1102
44E R/W 0 = Direct, 1 = Reverse (off if alarm active)
Output 1 Usage Outputs
1100
44C R/W
0 = Heat Output
1 = Cool Output
2 = Non-Linear Cooling – Only Extrusion
3 = Alarm 1
4 = Alarm 2
5 = Alarm 1 or Alarm 2
6 = Loop Alarm
