CIGWELD WeldSkill 200AC/DC - Volt-Ampere Curves

Safety and Installation 3-6 Manual 0-5206
WELDSKILL 200AC/DC INVERTER SAFETY AND INSTALLATION
3.07 Volt-Ampere Curves
Voltage-Amperage Curves shows maximum voltage and amperage output capabilities of welding power source.
Curves of other settings fall between curves shown.
A-11420
0
10
20
30
40
50
60
70
80
90
100
020406080100 120140 160180 200 220 240
W
elding Current (AMPS)
Output Voltage (Volts)
WELDSKILL 200AC/DC
MMAW (STICK)
GTAW(TIG
)
Figure 3-2: WELDSKILL 200AC/DC Volt-Ampere Curves
