CIGWELD WeldSkill 200AC/DC - Power Switch, Fan, and Power Cord Removal

Manual 0-5206 7-11 Disassembly Procedure
DISASSEMBLY PROCEDURE WELDSKILL 200AC/DC INVERTER
7.13 Power Switch S1, Fan and Power Cord Removal
!
Read and follow safety information in Section 6.02 before proceeding with disassembly
1. Remove 3 switch screws.
2. Remove power cord screw.
3. Disconnect wire from switch terminals.
4. Remove magnetic from ground wire.
5. Remove fan.
6. Pull out power cord.
1
6
2
5
3
4
A-11442
