Read and follow safety information in Section 6.02 before proceeding with disassembly
1. Remove screw.
2. Disconnect output harness from output Connector.
3 Disconnect input harness from input connector.
4. Disconnect SOU harness from SOU connector
5. Disconnect HF harness from HF connector.
6. Remove glue then pull out board.
6
3
2
1
5
4
A-11434
To Next Page
