ASSEMBLY PROCEDURE WELDSKILL 200AC/DC INVERTER
Manual 0-5206 8-5 Assembly Procedures
8.05 Installing PCB5
1. Install wire to terminals , tighten screws.
1
A-11436
8.06 Installing PCB4
1. Install 4 screws.
2. install wire to terminals and tighten.
3. Reconnect 2 yellow wires.
1
2
3
A-11446
