KEY SPARE PARTS 9-2 Manual 0-5206
WELDSKILL 200AC/DC INVERTER KEY SPARE PARTS
WeldSkill 200AC/DC Spare Parts
Item Part Number Description
1 W7005500 PCB display
2 W7005503 PCB aux power supply
3 W7005502 PCB HF
4 W7005504 PCB primary inverter
5 W7005505 PCB AC output drive
6 W7005506 PCB control
7 W7005507 PCB secondary rectifier
8 W7005508 PCB EMC filter
9 W7005509 Coil coupling
10 W7005512 Fan assembly
11 W7003033 Gas solenoid assembly
12
W7005513 Dinse Socket 50mm²
13 W7003036 Control socket 8 pin, (Note that 8 pin control plug part number is
UOA706900)
14 W7005514 Gas outlet, front panel
15 W7005515 Switch On/Off
16 W7003076 CT, output
17 704461 Dinse plug male 50mm² (not shown)
Table 9-1
