Chapter 3
Changin
g
Symbology Settings
3.17 UCC COUPON EXTENDED CODE
Decide whether to decode the follo
wi
ng barcodes as Coupon Code.
UPC-A barcodes starti
ng with digit “5”
EAN-13 barcodes starti
ng with digits “99”
UPC-A/EAN-128 Coupon Codes
Enable
*Disable
Note:
Depending on requirements, UP
C-A, EA
N-13 a
nd EAN-128 must be en
abled first!
