58
Enter Setup
1504 Barcode Scanner
User Guide
2.4 DIRECT USB VCOM
For USB Virtual COM, connect the scanner to the USB port of PC. Run HyperTerminal.exe
on the computer, and the scanned data will be transmitted to the computer.
Note: If using USB Virtual COM for the first time, it must install its driver from the
CD-ROM. Driver version 5.3 or later is required. Please remove older versions! For
1504 to connect to Windows PC, it must select Direct USB VCOM_CDC. Refer to
2.5 Direct USB VCOM_CDC.
2.4.1 ACTIVATE USB VIRTUAL COM
Activate Direct USB
Virtual COM
2.4.2 INTER-FUNCTION DELAY
By default, the inter-function delay is set to zero. Specify a value, ranging from 0 to 254
in units of millisecond, to match the computer response time of the keyboard interface.
Such delay time is inserted between every function code (0x01 ~ 0x1F) being
transmitted. The longer the delay time is, the slower the transmission speed will be.
Inter-Function
Delay… (*0~254)
1) Read the barcode above to specify the inter-function delay.
2) Read the “
Decimal Value” barcode on page 193 for the desired inter-function delay
(millisecond).
3) Read the “Validate” barcode on the same page to complete this setting.
To Next Page
