Chapter 2
Selectin
Output Interface
2.1.1 ACTIVATE KEYBOARD WEDGE & SELECT KEYBOARD TYPE
When Keyboard Wedge interface is activated, it will have to select a keyboard type to
complete this setting.
Activate Keyboard
Wedge & Select
Keyboard Type…
1) Read this barcode above to activate Keyboard Wedge and select a keyboard type.
2) Read the “
Decimal Value” barcode on page 193. Refer to the table below for the
number of desired keyboard type.
3) Read the “Validate” barcode on the same page to complete this setting.
Keyboard Type
By default, the keyboard type is set to PCAT (US). The following keyboard types are supported –
No. Keyboard Type No.
Keyboard Type
1 PCAT (US) 16 PS55 001-2
2 PCAT (French) 17 PS55 001-82
3 PCAT (German) 18 PS55 001-3
4 PCAT (Italian) 19 PS55 001-8A
5 PCAT (Swedish) 20 PS55 002-1, 003-1
6 PCAT (Norwegian) 21 PS55 002-81, 003-81
7 PCAT (UK) 22 PS55 002-2, 003-2
8 PCAT (Belgium) 23 PS55 002-82, 003-82
9 PCAT (Spanish) 24 PS55 002-3, 003-3
10 PCAT (Portuguese) 25 PS55 002-8A, 003-8A
11 PS55 A01-1 26 IBM 3477 Type 4 (Japanese)
12 PS55 A01-2 (Japanese) 27 PS2-30
13 PS55 A01-3 28 IBM 34XX/319X, Memorex Telex 122 Keys
14 PS55 001-1 29 User-defined table
15 PS55 001-81 30 PCAT (Turkish)
31 PCAT (Hungarian)
To Next Page
