191
Update
Appendix III
Keyboard
Wedge
Table
KEY TYPE & STATUS
KEY TYPE
If “Keyboard Wedge” or “USB HID” is
configur
ed for interface, Key Type and Key Status
will then become applic
able.
*Normal
Scan Code
KEY STATUS
Decide whether or not to cha
nge key status
when “Normal Key” is selected for Ke
y Type.
Add Shift
Add Left Ctrl
Add Right Ctrl
Add Left Alt
Add Right Alt
202
204
