1.4 BEEPER
The scanner has a buzzer to provide user feedback in various operating conditions.
Beeping
Meaning
One long beep, high tone Power on, with red LED on (1 second) and off quickly
One short beep, high tone
Programmable, default to 4 KHz
Good Read, with green LED on-off quickly
Six short beeps
High-low tone repeats three times
Enter Configuration Mode, with red LED flashing
Exit Configuration Mode
Two beeps, low-high tone
Setup barcode read successfully
Two beeps, high-low tone RS-232/USB Virtual COM connection fails (data saved in
Transmit Buffer), with red LED on-off quickly
One short beep, high tone More setup barcode required
One short beep, low tone More barcodes required to complete the “output
sequence” requirements of Multi-Barcode Editor, with
green LED on-off quickly (Upon completion, same as
Good Read.)
One long beep, low tone
Transmit buffer full, with red LED on-off quickly
Configuration error (Wrong barcode…)
Two long beeps, high-low tone Multi-Barcode Mode – Buffer full
1.4.1 BEEPER VOLUME
Mute
Minimum Volume
Medium Volume
*Maximum Volume
To Next Page
