Chapter 4
Changin
g
Symbology Settings
4.3.3 CONVERT TO EAN-13
Decide whether to co
nvert a 14-character barcode into
EAN-13 if the foll
owing
requirements are met:
The barcode must have a leading
0 and a valid EAN-13 check digit.
“Verify Check Digit”
must be disabled.
Convert to EAN-13
*Do Not Convert
129
