128
Enter Setup
1664 Barcode Scanne
r
User Guide
4.8 TRIOPTIC CODE 39
Decide whether to deco
de Trioptic Code 39.
Trioptic Code 39 is a variant of C
ode 39 used in the marking of computer t
ap
cartridges. It always co
ntains six characters.
Enable
*Disable
Note:
Trioptic Code 39 and Code 39 Full ASC
II cannot be enabled at the same time.
138
140
