Chapter 1
Understandin
he Barcode Scanner
1.4 BEEPER
The scanner has a buzzer to provide user feedback in various operating conditions.
Beeping
Meaning
One long beep, high tone Power on, with red LED on (1 second) and off quickly
One long beep, low tone
Transmit buffer full, with red LED on-off
Transmit buffer disabled, with red LED on-off
Configuration error (Wrong barcode…)
PIN code input error
Reject random PIN request
Failed to send data in memory mode
One short beep, high tone
Programmable, default to 4 KHz
Good Read, with green LED on-off
One short beep, high tone
More setup barcodes required
Input PIN code
Clear PIN code
One short beep, low tone More barcodes required to complete the “output sequence”
requirements of Multi-Barcode Editor, with green LED on-off
(Upon completion, same as Good Read.)
Six short beeps
High-low tone repeats three
times
Enter Configuration Mode, with red LED flashing
Exit Configuration Mode
Two short beeps, low-high tone Setup barcode read successfully
Two short beeps, high tone
Low Battery Alarm
Power off, with red LED on (until the key is released)
Delete the last collected data in memory mode, with red
LED on (1 second) and off
Wake up the scanner depends on the paging setting
value until the power key is pressed or the sleeping time
out is reached
Two short beeps, high-low tone
Data saved to buffer when transmit buffer is enabled
and the scanner is out of range, with red LED on-off
Memory Mode – Memory full, with red LED on-off
Memory Mode – Transmission failed, with red LED
flashing
Two long beeps, high-low tone Multi-Barcode Mode – Buffer full
Three short beeps, tone ascending
from high to low
WPAN connection out of range or suspended
Three short beeps, tone ascending
from low to high
WPAN connection established, with blue LED flashing
WPAN connection resumed, with blue LED flashing
