The scanner allows advanced data editing by applying user-configured editing formats.
The whole processed data can be divided into fields by user-specified rules. These fields
together with the user-configurable additional fields consist of the data actually sent to
the host computer.
For 1664 to apply any editing format, the maximum output data length of a barcode is 7
KB after configuration. When the data length exceeds 7 KB, editing format will not take
effect.
[Time
Stamp]
[Prefix
Code]
[Code
ID]
[Length
Code]
[Data]
Additional
Field(s)
[Time
Stamp]
[Suffix
Code]
None
by
default
None
by
default
None
by
default
None
by
default
Barcode
itself
None
by
default
None
by
default
0x0d
by
default
IN THIS CHAPTER
6.1 Activating Editing Formats..........................................200
6.2 How to Configure Editing Formats ...............................202
6.3 Configuring Format — Define Data Criteria ...................205
6.4 Configuring Format — Define Data Field .......................217
6.5 Configuring Format — Define Transmission Sequence ....226
6.6 Programming Examples .............................................228
Chapter 6
APPLYING FORMATS FOR DATA EDITING
