CipherLab 1664

84
Enter Setup
1664 Barcode Scanner User Guide
2.6.1 ACTIVATE USB HID & SELECT KEYBOARD TYPE
When USB HID interface is activated, please select a keyboard type to complete this
setting.
Activate
Direct USB HID &
Select Keyboard
Type…
1) Read the barcode above to activate USB HID and select a keyboard type.
2) Read the “
Decimal Value” barcode page 251 . Refer to the table below for the number
of desired keyboard type.
3) Read the “Validate” barcode on the same page to complete this setting.
USB HID
By default, the keyboard type is set to PCAT (US). The following keyboard types are supported —
No. Keyboard Type No. Keyboard Type
64 HID PCAT (US) 71 HID PCAT (Belgium)
65 HID PCAT (French) 72 HID PCAT (Spanish)
66 HID PCAT (German) 73 HID PCAT (Portuguese)
67 HID PCAT (Italy) 74 HID A01-2 (Japanese)
68 HID PCAT (Swedish) 75 User-Defined Table
69 HID PCAT (Norwegian) 76 HID PCAT (Turkish)
70 HID PCAT (UK) 77 HID PCAT (Hungarian)
