151
Update
Chapter 4
Changin
g
Symbology Settings
4.20 CODE 11
Enable
*Disable
4.20.1 VERIFY CHECK DIGIT
Decide whether to verify t
he ch
eck digit(s). If incorrect, the
barcode will not be accepted.
Verify One
Check Digit
Verify Two
Check Digit
*Do Not Verify
4.20.2 TRANSMIT CHECK DIGIT
Decide whether to inclu
de the check digit(s) in the da
ta being transmitted.
Transmit Code 11
Check Digit
*Do Not Transmit
Note:
"Verify Check Digit" mu
st be enabled first.
161
