Cisco IAD2430 Series Integrated Access Devices Software Configuration Guide
OL-4306-03
Chapter 1 Understanding Interface Numbering and Cisco IOS Software Basics
Identifying Cisco IAD2430 Models
Figure 1-1 Cisco IAD2430-24FXS Chassis—Front Panel
Figure 1-2 Cisco IAD2435-8FXS Chassis—Front Panel
Cisco IAD2431-8FXS IAD
The Cisco IAD2431-8FXS provides eight analog FXS ports, two 10/100BASE-T ports, and one T1/E1
WAN port. The chassis has the following interfaces (see
Figure 1-3):
• RJ-21 analog voice interface
• One T1/E1 port
• One 10/100BASE-T port
• One WIC/VIC slot
• External flash memory
• AC and DC power adapter
Figure 1-3 Cisco IAD2431-8FXS Chassis—Back Panel
88839
CISCO IAD2400
231872
Cisco IAD2400 SERIES
OK
0/0
0/1
FE
T1/E1
FXS
CD
AL
2/0 2/1
2/2
2/3 2/4 2/5
2/6 2/7
88825
IAD2431-8FXS
