3-23
Cisco IAD2430 Series Integrated Access Devices Software Configuration Guide
OL-4306-03
Chapter 3 Configuring with the Command-Line Interface
Configuring a WIC-1DSU-T1/E1 Serial WAN Interface Card
Ta b l e 3-2 Clock Rate Settings for 1-Port/2-Port Serial WAN Interface Card in Synchronous
Mode
Timer (bits per
second)
Syntax (bits per
second)
Default Setting (bits
per second)
1200 38400 148000
2400 56000 500000
4800 57600 800000
9600 64000 1000000
14400 72000 1300000
19200 115200 2000000
28800 125000 4000000
32000 128000 148000
Ta b l e 3-3 Clock Rate Settings for 2-Port Synchronous Serial WAN Interface Card
Timer (bits per
second)
Syntax (bits per
second)
Default Setting (bits
per second)
1200 28800 72000
2400 32000 115200
4800 38400 125000
9600 56000 128000
14400 57600 —
19200 64000 —
Ta b l e 3-4 Clock Rate Settings for 4-Port Synchronous Serial Interface Card
Timer (bits per
second)
Syntax (bits per
second)
Default Setting (bits
per second)
300 19200 64000
1200 28800 72000
2400 32000 115200
4800 38400 128000
9600 56000 —
14400 57600 —
