Chapter 3 Configuring with the Command-Line Interface
Configuring T1/E1 Interfaces
Example
The following example shows typical DS0 groups configuration:
controller T1 0/0
channel-group 0 timeslots 1-20 speed 64
ds0-group 1 timeslots 21-24 type fxo-loopstart
!
voice-port 0/0:1
!
voice-port 0/1/0 << FXS
!
dial-peer voice 1 pots
description calls to PSTN - dial 9 from FXS
destination-pattern 9T
port 0/0:1
!
dial-peer voice 2 pots
description calls to Analog phone from PSTN
destination-pattern 4083333333
port 0/1/0
0
Configuring TDM Cross-Connect
For multiflex trunk interfaces using the time-division multiplexing (TDM) connect function, you can use
the connect command to cross-connect (1) two TDM groups from two controllers, or (2) an analog FXS
port and a DS0 group on a T1. Cross-connecting is done differently for data and voice, as shown in the
following procedures:
• Configuring TDM to TDM
• Configuring TDM to Analog Voice Port
Step 12
exit
Example:
Router(config-if)# exit
Exits to global configuration mode.
Step 13
Ctrl-z
Example:
Router#
Returns to enable mode when you finish configuring
interfaces.
