Cisco 2431 - IAD Router - TDM Cross-Connect

3-19
Cisco IAD2430 Series Integrated Access Devices Software Configuration Guide
OL-4306-03
Chapter 3 Configuring with the Command-Line Interface
Configuring T1/E1 Interfaces
Note The serial interface must be a DTE device.
SUMMARY STEPS
1. enable
2. configure terminal
3. tdm-group tdm-group-no timeslot timeslot-list
4. exit
5. interface type number
6. no keepalive
7. exit
8. connect
DETAILED STEPS
Command or Action Purpose
Step 1
enable
Example:
Router# enable
Enters privileged EXEC mode.
Step 2
configure terminal
Example:
Router# configure terminal
Enters global configuration mode.
Step 3
tdm-group tdm-group-no timeslot timeslot-list
Example:
Router(config-controller)# tdm-group 1 timeslot
13-20
Configures a list of time slots for creating clear channel
groups (pass-through) for time-division multiplexing
(TDM) cross-connect.
When configuring cross-connect for data traffic only, do
not specify the type option.
Step 4
exit
Example:
Router(config-controller)# exit
Exits to global controller mode.
Step 5
interface type number
Example:
Router(config-controller)# interface serial 1/0:0
Configures the serial interface.
Step 6
no keepalive
Example:
Router(config-if)# no keepalive
Sets the no keepalive function.
