Cisco 2431 - IAD Router User Manual

1-9
Cisco IAD2430 Series Integrated Access Devices Software Configuration Guide
OL-4306-03
Chapter 1 Understanding Interface Numbering and Cisco IOS Software Basics
Cisco IAD2430 Series Deployment Scenarios
Cisco IAD2430 Series Deployment Scenarios
Figure 1-9 through Figure 1-9 on page 1-9 show some typical deployment scenarios for Cisco IAD2430
series IADs.
Figure 1-9 Analog FXS User Interface with Metro Ethernet Interface
Figure 1-10 T1/E1 WAN Interface with Analog FXS User Interface
IAD
RJ-21
Ethernet
Distribution
panel
88997
Cisco IAD model number:
IAD2430-24FXS
Analog
telephones
IAD
WAN
T1 RJ-21
Ethernet
Analog
telephones
Distribution
panel
88998
Cisco IAD model number:
IAD2431-8FXS
IAD2431-16FXS
IAD2432-24FXS
IAD2435-8FXS
