Cisco 2431 - IAD Router User Manual

3-25
Cisco IAD2430 Series Integrated Access Devices Software Configuration Guide
OL-4306-03
Chapter 3 Configuring with the Command-Line Interface
Configuring a VIC2-2FXO or VIC2-4FXO Voice Interface Card
SUMMARY STEPS
1. enable
2. configure terminal
3. voice-port slot/port
4. connection
5. dial-type
6. signal
7. compand-type
8. cptone local
9. description string
10. exit
11. Ctrl-z
DETAILED STEPS
Command or Action Purpose
Step 1
enable
Example:
Router# enable
Enters privileged EXEC mode.
Step 2
configure terminal
Example:
Router# configure terminal
Enters global configuration mode.
Step 3
voice-port slot/port
Example:
Router(config)# voice-port 0/1
Enters voice-port configuration mode. See Port
Numbering Conventions, page 1-5.
Step 4
connection {trunk|plar|tie-line|plar-opx} string
Example:
Router(config-voice-port)# connection tie-line
5550100
Configures the voice-port connection mode type and the
destination telephone number.
The plar value is used for private line automated
ringdown (PLAR) connections. The tie-line value is used
for a tie-line connection to a PBX. The plar-opx value,
for PLAR off-premises extension, allows the local voice
port to provide a local response before the remote voice
port receives an answer.
Step 5
dial-type {pulse|dtmf|mf}
Example:
Router(config-voice-port)# dial-type pulse
Configures the voice-port dial-type. The default is dtmf.
