All interface configuration tasks for Gigabit Ethernet interfaces still must be performed in interface configuration
mode.
Note
Configuring the Optical Parameters
This task describes how to configure the wavelength parameters for the DWDM controller to set the operational
wavelength of a tunable SFP+ module. The DWDM controllers are configured in the physical layer control
element of the Cisco IOS XR software configuration space.
SUMMARY STEPS
1. configure
2. controller dwdm interface-path-id
3. admin-state out-of-service
4. commit
5. wavelength channel-number
6. commit
7. admin-state in-service
8. Do one of the following:
• end
•
• commit
9. show controllers dwdm interface-path-id optics
DETAILED STEPS
PurposeCommand or Action
Enter the XR Config mode.configure
Example:
Step 1
RP/0/RP0/CPU0:router# configure
Specifies the DWDM controller name in the notation
rack/slot/module/port and enters DWDM configuration
mode.
controller dwdm interface-path-id
Example:
RP/0/RP0/CPU0:router(config)# controller dwdm
0/1/0/0
Step 2
Example:
RP/0/RP0/CPU0:router(config-dwdm)#
Interface and Hardware Component Configuration Guide for Cisco NCS 6000 Series Routers, IOS XR Release 6.4.x
131
Configuring Dense Wavelength Division Multiplexing Controllers
Configuring the Optical Parameters
