PurposeCommand or Action
Example:
• Entering yes saves configuration changes to the
running configuration file, exits the configuration
session, and returns the router to XR EXEC mode.
•
Example:
RP/0/RP0/CPU0:router(config-if)# commit
• Entering no exits the configuration session and
returns the router to XR EXEC mode without
committing the configuration changes.
• Entering cancel leaves the router in the current
configuration session without exiting or
committing the configuration changes.
• Use the commit command to save the configuration
changes to the running configuration file and remain
within the configuration session.
Configuring VLAN Bundles
This section describes how to configure a VLAN bundle. The creation of a VLAN bundle involves three main
tasks:
1. Create an Ethernet bundle
2. Create VLAN subinterfaces and assign them to the Ethernet bundle.
3. Assign Ethernet links to the Ethernet bundle.
These tasks are describe in detail in the procedure that follows.
In order for a VLAN bundle to be active, you must perform the same configuration on both ends of the bundle
connection.
Note
SUMMARY STEPS
1. configure
2. interface Bundle-Ether bundle-id
3. ipv4 address ipv4-address mask
4. bundle minimum-active bandwidth kbps
5. bundle minimum-active links links
6. bundle maximum-active links links [hot-standby]
7. lacp fast-switchover
8. exit
9. interface Bundle-Ether bundle-id.vlan-id
10. ipv4 address ipv4-address mask
11. no shutdown
12. exit
13. Repeat Step 9 through Step 12 to add more VLANS to the bundle you created in Step 2.
14. Do one of the following:
• end
Interface and Hardware Component Configuration Guide for Cisco NCS 6000 Series Routers, IOS XR Release 6.4.x
78
Configuring Link Bundling
Configuring VLAN Bundles
