Page #89 background imageLoading...
Page #89 background image
SUMMARY STEPS
1. configure
2. interface Bundle-Ether bundle-id l2transport
3. Do one of the following:
bundle load-balance hash hash-value [auto]
4. Do one of the following:
end
commit
DETAILED STEPS
PurposeCommand or Action
Enters XR configuration mode.configure
Example:
Step 1
RP/0/RP0/CPU0:router# configure
Creates a new Ethernet link bundle with the specified
bundle-id and with Layer 2 transport enabled.
interface Bundle-Ether bundle-id l2transport
Example:
Step 2
The range is 1 to 65535.
RP/0/RP0/CPU0:router#(config)# interface
Bundle-Ether 3 l2transport
Configures all egressing traffic on the fixed members of a
bundle to flow through the same physical member link.
Do one of the following:
Step 3
bundle load-balance hash hash-value [auto]
hash-value—Numeric value that specifies the physical
member link through which all egressing traffic in this
bundle will flow. The values are 1 through 8.
Example:
RP/0/RP0/CPU0:router(config-subif)# bundle
load-balancing hash 1
auto—The physical member link through which all
egressing traffic on this bundle will flow is
automatically chosen.
Example:
Example:
RP/0/RP0/CPU0:router(config-subif)# bundle
load-balancing hash auto
Saves configuration changes.Do one of the following:
Step 4
end When you issue the end command, the system prompts
you to commit changes:
commit
Uncommitted changes found, commit them before
Example:
exiting(yes/no/cancel)?
[cancel]:
RP/0/RP0/CPU0:router(config-if)# end
Interface and Hardware Component Configuration Guide for Cisco NCS 6000 Series Routers, IOS XR Release 6.4.x
77
Configuring Link Bundling
Configuring EFP Load Balancing on an Ethernet Link Bundle
