PurposeCommand or Action
one of the supported commands on the platform in interface
Ethernet OAM configuration mode.
Saves the configuration changes to the running configuration
file and remains within the configuration session.
commit
Example:
Step 5
RP/0//CPU0:router(config-if)# commit
Ends the configuration session and exits to the EXEC mode.end
Example:
Step 6
RP/0//CPU0:router(config-if)# end
Verifying the Ethernet OAM Configuration
Use the show ethernet oam configuration command to display the values for the Ethernet OAM configuration
for a particular interface, or for all interfaces. The following example shows the default values for Ethernet
OAM settings:
RP/0/RP0/CPU0:router# show ethernet oam configuration
Thu Aug 5 22:07:06.870 DST
GigabitEthernet0/4/0/0:
Hello interval: 1s
Link monitoring enabled: Y
Remote loopback enabled: N
Mib retrieval enabled: N
Uni-directional link-fault detection enabled: N
Configured mode: Active
Connection timeout: 5
Symbol period window: 0
Symbol period low threshold: 1
Symbol period high threshold: None
Frame window: 1000
Frame low threshold: 1
Frame high threshold: None
Frame period window: 1000
Frame period low threshold: 1
Frame period high threshold: None
Frame seconds window: 60000
Frame seconds low threshold: 1
Frame seconds high threshold: None
High threshold action: None
Link fault action: Log
Dying gasp action: Log
Critical event action: Log
Discovery timeout action: Log
Capabilities conflict action: Log
Wiring conflict action: Error-Disable
Session up action: Log
Session down action: Log
Remote loopback action: Log
Require remote mode: Ignore
Require remote MIB retrieval: N
Require remote loopback support: N
Require remote link monitoring: N
Interface and Hardware Component Configuration Guide for Cisco NCS 6000 Series Routers, IOS XR Release 6.4.x
58
Configuring Ethernet OAM
Verifying the Ethernet OAM Configuration
