PurposeCommand or Action
• Use the commit command to save the configuration
changes to the running configuration file and remain
within the configuration session.
Configuring Custom LACP Short Period Time Intervals
This section describes how to configure custom short period time intervals (less than 1000 milliseconds) for
sending and receiving LACP packets on a Gigabit Ethernet interface.
You must always configure the transmit interval at both ends of the connection before you configure the
receive interval at either end of the connection. Failure to configure the >transmit interval at both ends first
results in route flapping (a route going up and down continuously). When you remove a custom LACP short
period, you must do it in reverse order. You must remove the receive intervals first and then the transmit
intervals.
Note
SUMMARY STEPS
1. configure
2. interface Bundle-Ether bundle-id
3. ipv4 address ipv4-address mask
4. bundle minimum-active bandwidth kbps
5. bundle minimum-active links links
6. bundle maximum-active links links
7. exit
8. interface Bundle-Ether bundle-id.vlan-id
9. dot1q vlan vlan-id
10. ipv4 address ipv4-address mask
11. no shutdown
12. exit
13. Repeat Step 7 through Step 12 to add more VLANs to the bundle you created in Step 2.
14. Do one of the following:
• end
•
• commit
15. exit
16. exit
17. show ethernet trunk bundle-ether instance
18. configure
19. interface {GigabitEthernet | TenGigE} interface-path-id
20. bundle id bundle-id [mode {active | on | passive}]
21. no shutdown
22. Repeat Step 19 through Step 21 to add more Ethernet interfaces to the VLAN bundle.
Interface and Hardware Component Configuration Guide for Cisco NCS 6000 Series Routers, IOS XR Release 6.4.x
86
Configuring Link Bundling
Configuring Custom LACP Short Period Time Intervals
