Verifying the LLDP Configuration
This section describes how to verify the LLDP configuration both globally, and for a particular interface.
Verifying the LLDP Global Configuration
To verify the LLDP global configuration status and operational characteristics, use the show lldp command
as shown in this example:
RP/0/RP0/CPU0:router# show lldp
Wed Apr 13 06:16:45.510 DST
Global LLDP information:
Status: ACTIVE
LLDP advertisements are sent every 30 seconds
LLDP hold time advertised is 120 seconds
LLDP interface reinitialisation delay is 2 seconds
If LLDP is not enabled globally, this output appears when you run the show lldp command:
RP/0/RP0/CPU0:router# show lldp
Wed Apr 13 06:42:48.221 DST
% LLDP is not enabled
Verifying the LLDP Interface Configuration
To verify the LLDP interface status and configuration, use the show lldp interface command as shown in
this example:
RP/0/RP0/CPU0:router# show lldp interface GigabitEthernet 0/1/0/7
Wed Apr 13 13:22:30.501 DST
GigabitEthernet0/1/0/7:
Tx: enabled
Rx: enabled
Tx state: IDLE
Rx state: WAIT FOR FRAME
What To Do Next
To monitor and maintain LLDP on the system or get information about LLDP neighbors, use one of these
commands:
DescriptionCommand
Resets LLDP traffic counters or LLDP neighbor informationclear lldp
Displays detailed information about LLDP neighborsshow lldp entry
Displays LLDP error and overflow statisticsshow lldp errors
Displays information about LLDP neighborsshow lldp
neighbors
Displays statistics for LLDP trafficshow lldp traffic
Interface and Hardware Component Configuration Guide for Cisco NCS 6000 Series Routers, IOS XR Release 6.4.x
43
Configuring Ethernet Interfaces
Verifying the LLDP Configuration
