Turning On the Laser: Example
This is a required configuration. The DWDM cards will not operate without this configuration.
Note
The following example shows how to turn on the laser and place a DWDM port in In Service (IS) state:
RP/0/RP0/CPU0:router# configure
RP/0/RP0/CPU0:Router(config)# controller dwdm 0/1/0/1
RP/0/RP0/CPU0:Router(config-dwdm)# admin-state in-service
RP/0/RP0/CPU0:Router(config-dwdm)# commit
Turning Off the Laser: Example
The following example shows how to turn off the laser, stop all traffic and place a DWDM port in Out of
Service (OOS) state:
RP/0/RP0/CPU0:router# configure
RP/0/RP0/CPU0:Router(config)# controller dwdm 0/1/0/1
RP/0/RP0/CPU0:Router(config-dwdm)# admin-state out-of-service
RP/0/RP0/CPU0:Router(config-dwdm)# commit
IPoDWDM Configuration: Examples
This section includes the following examples:
Optical Layer DWDM Port Configuration: Examples
The following example shows how to configure Optical Layer DWDM ports.
RP/0/RP0/CPU0:router# configure
RP/0/RP0/CPU0:router(config)# controller dwdm 0/1/0/1
RP/0/RP0/CPU0:router(config-dwdm)# network port id 1/0/1/1
RP/0/RP0/CPU0:router(config-dwdm)# network connection id 1/1/1/1
Administrative State of DWDM Optical Ports Configuration: Examples
The following examples show how to configure the administrative state and optionally set the maintenance
embargo flag:
RP/0/RP0/CPU0:router# configure
RP/0/RP0/CPU0:router(config)# controller dwdm 0/1/0/1
RP/0/RP0/CPU0:router(config-dwdm)# admin-state in-service
RP/0/RP0/CPU0:router(config-dwdm)# exit
RP/0/RP0/CPU0:router(config)# interface tengige 1/0/1/1
Interface and Hardware Component Configuration Guide for Cisco NCS 6000 Series Routers, IOS XR Release 6.4.x
139
Configuring Dense Wavelength Division Multiplexing Controllers
Turning On the Laser: Example
