DETAILED STEPS
PurposeCommand or Action
Enters XR configuration mode.configure
Example:
Step 1
RP/0/RP0/CPU0:router# configure
Enters interface configuration mode and specifies the
Management Ethernet interface name and instance.
interface MgmtEth interface-path-id
Example:
Step 2
RP/0/RP0/CPU0:router(config)# interface MgmtEth
0/RP0/CPU0/0
Configures the MAC layer address of the Management
Ethernet interface.
mac-address address
Example:
Step 3
To return the device to its default MAC address,
use the no mac-address address command.
Note
RP/0/RP0/CPU0:router(config-if)# mac-address
0001.2468.ABCD
Saves configuration changes.Do one of the following:
Step 4
• end • When you issue the end command, the system prompts
you to commit changes:
• or
• commit
Uncommitted changes found, commit them before
Example:
exiting(yes/no/cancel)?
[cancel]:
RP/0/RP0/CPU0:router(config-if)# end
• • Entering yes saves configuration changes to the
running configuration file, exits the configuration
session, and returns the router to XR EXEC mode.
Example:
RP/0/RP0/CPU0:router(config-if)# commit
• Entering no exits the configuration session and
returns the router to XR EXEC mode without
committing the configuration changes.
• Entering cancel leaves the router in the current
configuration session without exiting or
committing the configuration changes.
• Use the commit command to save the configuration
changes to the running configuration file and remain
within the configuration session.
Verifying Management Ethernet Interface Configuration
Perform this task to verify configuration modifications on the Management Ethernet interfaces for the RPs.
SUMMARY STEPS
1. show interfaces MgmtEth interface-path-id
2. show running-config interface MgmtEth interface-path-id
Interface and Hardware Component Configuration Guide for Cisco NCS 6000 Series Routers, IOS XR Release 6.4.x
18
Advanced Configuration and Modification of the Management Ethernet Interface
Verifying Management Ethernet Interface Configuration
