DETAILED STEPS
PurposeCommand or Action
Enters global configuration mode.configure
Example:
Step 1
RP/0/RP0/CPU0:router# config
Specifies the DWDM controller and enters DWDM
controller mode.
controller dwdm interface-path-id
Example:
Step 2
RP/0/RP0/CPU0:router(config)# controller dwdm
0/1/0/1
Assigns an identifier number to a port for the Multi Service
Transport Protocol (MSTP).
network port id id-number
Example:
Step 3
RP/0/RP0/CPU0:router(config-dwdm)# network port id
1/0/1/1
Configures a connection identifier for the Multi Service
Transport Protocol (MSTP).
network connection id id-number
Example:
Step 4
RP/0/RP0/CPU0:router(config-dwdm)# network
connection id 1/1/1/1
Saves configuration changes.Do one of the following:
Step 5
end When you issue the end command, the system prompts
you to commit changes:
commit
Uncommitted changes found, commit them before
exiting(yes/no/cancel)? [cancel]:
Example:
RP/0/RP0/CPU0:router(config-dwdm)# end
Entering yes saves configuration changes to the
running configuration file, exits the configuration
session, and returns the router to EXEC mode.
Example:
Example:
Entering no exits the configuration session and
returns the router to EXEC mode without
committing the configuration changes.
RP/0/RP0/CPU0:router(config-dwdm)# commit
Entering cancel leaves the router in the current
configuration session without exiting or
committing the configuration changes.
Use the commit command to save the configuration
changes to the running configuration file and remain
within the configuration session.
Interface and Hardware Component Configuration Guide for Cisco NCS 6000 Series Routers, IOS XR Release 6.4.x
136
Configuring Dense Wavelength Division Multiplexing Controllers
Configuring the Optical Layer DWDM Ports
