3-27
Cisco 7600 Series Router Installation Guide
OL-4503-26
Chapter 3 Installing the Cisco 7600 Series Router
Attaching the Interface Cables
• 9600 baud
• 8 data bits
• No parity
• 2 stop bits
To connect a terminal using a Catalyst 5000 family Supervisor Engine III console cable, perform these
steps:
Step 1 Place the console port mode switch in the out position.
Step 2 Connect to the port using the Supervisor Engine III cable and the appropriate adapter for the terminal
connection.
Step 3 Position the cable in the cable guide (if installed). Make sure there are no sharp bends in the cable.
Step 4 Check the terminal documentation to determine the baud rate. The baud rate of the terminal must match
the default baud rate (9600 baud) of the console port. Set up the terminal as follows:
• 9600 baud
• 8 data bits
• No parity
• 2 stop bits
To connect a modem to the console port, perform these steps:
Step 1 Place the console port mode switch in the in position.
Step 2 Connect to the port using the RJ-45-to-RJ-45 rollover cable and the RJ-45-to-DB-25 DCE adapter
(labeled “Modem”).
Step 3 Position the cable in the cable guide (if installed). Make sure there are no sharp bends in the cable.
Connecting the Supervisor Engine Uplink Ports
This section describes how to connect to the supervisor engine uplink ports.
Warning
Because invisible laser radiation may be emitted from the aperture of the port when no cable is
connected, avoid exposure to laser radiation and do not stare into open apertures.
Note In a redundant configuration with two supervisor engines, the uplink ports on the redundant (standby)
supervisor engine are active and can be used for normal traffic, like any other ports in the chassis.
To connect to the supervisor engine uplink ports, perform these steps:
