B-7
Cisco 7600 Series Router Installation Guide
OL-4503-26
Appendix B Connector and Cable Specifications
Cable Specifications
Cable Specifications
You can order a connector kit for the accessory kit that contains the cable and adapters you need to
connect a console (an ASCII terminal or PC running terminal emulation software) or modem to the
console port.
The accessory kit includes these items:
• RJ-45-to-RJ-45 rollover cable
• RJ-45-to-DB-9 female DTE adapter (labeled “Terminal”)
• RJ-45-to-DB-25 female DTE adapter (labeled “Terminal”)
• RJ-45-to-DB-25 male DCE adapter (labeled “Modem”)
The cable and adapters are the same cable and adapters that ship with the Cisco 2500 series routers and
other Cisco products.
Note The console cable is not shipped with the chassis, you can order the CONNECTOR-KIT as a spare if
required.
Console Port Mode Switch
The supervisor engine front-panel console port mode switch allows you to connect a terminal or modem
to the console port as follows:
Note Use a ballpoint pen tip or other small, pointed object to access the console port mode switch. The switch
is shipped in the in position.
• Mode 1—Switch in the in position. Use this mode to connect a terminal to the console port using
the RJ-45-to-RJ-45 rollover cable and DTE adapter (labeled “Terminal”).
You can also use this mode to connect a modem to the console port using the RJ-45-to-RJ-45
rollover cable and DCE adapter (labeled “Modem”).
See the “Console Port Mode 1 Signaling and Pinouts” section on page B-8.
DWDM-GBIC-35.04 1000BASE-DWDM 1535.04 nm GBIC 53
DWDM-GBIC-34.25 1000BASE-DWDM 1534.25 nm GBIC 54
DWDM-GBIC-32.68 1000BASE-DWDM 1532.68 nm GBIC 56
DWDM-GBIC-31.90 1000BASE-DWDM 1531.90 nm GBIC 57
DWDM-GBIC-31.12 1000BASE-DWDM 1531.12 nm GBIC 58
DWDM-GBIC-30.33 1000BASE-DWDM 1530.33 nm GBIC 59
Table B-2 DWDM GBIC Product Numbers and ITU Channel Numbers (continued)
DWDM GBIC
Product Number Description ITU Channel
