1-6
Cisco 7600 Series Router Installation Guide
OL-4503-26
Chapter 1 Product Overview
Cisco 7604 Router
Note The GBIC uplink ports are fully functional on the redundant supervisor engine in standby mode.
Slots 3 and 4 are available for OSMs or other supported Catalyst 6500 series modules.
The Cisco 7604 router supports the following supervisor engines:
Supervisor Engine 720 (with PFC3B or PFC3BXL)
Supervisor Engine 32
Route Switch Processor 720
Note The Cisco 7604 router does not support Supervisor Engine 2.
Note The Switch Fabric Module is not supported on the Cisco 7604 router.
The Cisco 7604 router also supports:
Up to three of the following hot-swappable line cards:
OSMs
Catalyst 6500 series modules
Carrier cards (SIP-200, SIP-400, SIP-600)
FlexWAN or Enhanced FlexWAN modules
Hot-swappable fan assembly
Redundant AC-input or DC-input power supplies (2700 W)
Redundant DC-input or DC-input power supplies (2700 W)
The power supplies are installed from the rear of the chassis. (See Figure 1-6.)
For a detailed description of supervisor engine operation in a redundant configuration, refer to the
Cisco
7600 Series Router Supervisor Engine and Route Switch Processor Guide.
